Intel Next Unit of Computing Kit NUC5CPYH

A Mini PC with the capabilities of a desktop, the Intel® NUC Kit NUC5CPYH gives you performance you can count on with Intel quality you can trust all in 4 inches square. Complete with WiFi 802.11ac, Bluetooth* 4.0, and 4 USB 3.0 ports, the NUC5CPYH is perfect as a PC replacement or second home computer. The system has room for a 2.5" HDD so you can store all your files or SSD drive so you can transfer data at lightning speeds. In addition, there is an SD card slot so you can easily access files from other devices on your Intel NUC Intel® NUC Kit NUC5CPYH nuc5cpyh memory nuc5cpyh windows 10

Intel Next Unit of Computing Kit NUC5CPYH - Barebone - mini PC - 1 x Celeron N3050 / 1.6 GHz - HD Graphics - GigE, Bluetooth 4.0 LE - WLAN : 802.11a/b/g/n/ac, Bluetooth 4.0 LE intel nuc5cpyh review nuc5cpyh drivers intel nuc5cpyh windows 7 nuc5cpyh price




 PRODUCT HIGHLIGHTS
  • Intel Braswell Celeron N3050
  • Internal support for 2.5" HDD or SSD
  • Intel HD Graphics
  • Consumer Infrared sensor on the front panel
  • 3-year limited warranty by Intel
  • Windows & Linux Compatible
  • One DDR3L SO-DIMM socket (up to 8 GB, 1333/1600 MHz) prepopulated with 2 GB DDR3L-1600 MHz
  • 1x SATA3 port for connection to 2.5" HDD or SSD
  • Intel Dual Band Wireless-AC and Bluetooth 4.0
  • Headphone/Microphone jack on the front panel
  • TOSLINK optical audio jack on the back panel
  • 2x USB 3.0 ports on the front panel
  • 2x USB 3.0 ports on the back panel
  • One HDMI 1.4b display port supporting 8 channel digital audio (7.1 surround sound)
  • VGA Port
  • Consumer infrared sensor
  • SD card slot
  • Support for user-replaceable third-party lids
  • Kensington lock support with base security



sales@ravirajtech.com

Buy Now

INR 7800 /-

Not Including Tax & shipping extra







Product Description

Intel Next Unit of Computing Kit NUC5CPYH - Celeron N3050 1.6 GHz - 0 MB - 0 GB

Type

PC barebone - mini PC

Processor

1 x Intel Celeron N3050 / 1.6 GHz ( 2.16 GHz ) ( Dual-Core )

Processor Main Features

Intel Burst Technology

Cache Memory

2 MB

Cache Per Processor

2 MB

RAM

0 MB (installed) / 8 GB (max) - DDR3L SDRAM

Storage Controller

SATA ( SATA 6Gb/s )

Hard Drive

No HDD

Graphics Controller

Intel HD Graphics

Audio Output

- 7.1 channel surround

Networking

GigE, 802.11b, 802.11a, 802.11g, 802.11n, 802.11ac, Bluetooth 4.0 LE

OS Provided

No operating system

Dimensions (WxDxH)

11.5 cm x 11.1 cm x 5.16 cm

Manufacturer Warranty

3 years warranty




General

Type

PC barebone

Product Form Factor

Mini PC

Built-in Devices

Infrared receiver

Processor / Chipset

CPU

Intel Celeron N3050 / 1.6 GHz

Max Turbo Speed

2.16 GHz

Number of Cores

Dual-Core

CPU Qty

1

Max CPU Qty

1

CPU Upgradability

Not upgradable

Processor Main Features

Intel Burst Technology

Cache Memory

Installed Size

2 MB

Cache Per Processor

2 MB

RAM

Installed Size

0 MB / 8 GB (max)

Technology

DDR3L SDRAM

Form Factor

SO-DIMM 204-pin

Hard Drive

Type

No HDD

Storage Controller

Type

SATA

Controller Interface Type

SATA 6Gb/s

Card Reader

Supported Flash Memory Cards

SDXC Memory Card

Monitor

Monitor Type

None.

Graphics Controller

Graphics Processor

Intel HD Graphics

Video Interfaces

HDMI, DisplayPort

Audio Output

Sound Output Mode

7.1 channel surround

Compliant Standards

High Definition Audio

Networking

Interface (Bus) Type

M.2 Card

Wireless LAN Supported

Yes

Wireless NIC

Intel Dual Band Wireless-AC 7265

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 4.0 LE

Features

ACPI support

Compliant Standards

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, Bluetooth 4.0, IEEE 802.11ac

Expansion / Connectivity

Bays

1 (total) / 1 (free) x internal 2.5"

Slots

1 (total) / 1 (free) x SO-DIMM 204-pin ¦ 1 (total) / 1 (free) x M.2 Card

Interfaces

4 x USB 3.0 ( 2 front, 2 rear ) ¦ 1 x Mini-HDMI ¦ 1 x VGA ¦ 1 x headphones/microphone ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x SPDIF output/headphones

Miscellaneous

Included Accessories

VESA mounting kit

Features

Security lock slot (cable lock sold separately), 1 USB 3.0 charging port

Power

Device Type

Power adapter

Power Provided

65 Watt

Operating System / Software

OS Provided

No operating system

Manufacturer Warranty

Service & Support

3 years warranty

Service & Support Details

Limited warranty - replacement - 3 years

Dimensions & Weight

Width

11.5 cm

Depth

11.1 cm

Height

5.16 cm

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

50 °C



How do you use your Intel NUC?

Multiple HD Displays: Because one HD screen is never enough.

Rapid Start: Less Waiting. More Gaming.

Multiple Ports: Room for the peripherals so you can drive like you do in real life.

Supports 4K Display: For immersive visuals.

Smaller Than a DVR: Or your grandma’s VCR.

Built-In WIFI: So you can stream all the Netflix* you want.



Vesa Mount: DIY your own All in One with a single screwdriver.

Bluetooth: Hook up your Bluetooth speakers and go all retro boombox cool.

Storage: Up to 2 TB of storage for all the pictures of kittens and tacos that you take.









:: Application

  • HTPC

  • Digital Signage

  • Media Center

  • Build Home Server

  • Compact desktop or mobile computer

  • Embedded Single Board Computer systems

  • Thin clients

  • Home theater











Hardware only

 Part number

MOQ

 Pricing

Intel NUC NUC5PPYH  Kit

Intel BOXNUC5CPYH Next Unit of Computing Kit

10

INR 7800.00/ per unit

Tax & shipping extra
